JETI Specbos 1211 Reference Spectroradiometer

Back to the Products Index ...

Questions? Contact us.



JETI Specbos 1211 with  ChromaPure
Professional

ChromaPure info


Our price: $8900 USD

FREE SHIPPING




JETI Specbos 1211
(Standalone)


Our price: $8800 USD

FREE SHIPPING




ADD-ONS
:

ADD-ON: Bluetooth

(Must be purchased at the same time as a JETI 1211)

Our price: $500 USD


ADD-ON: LAN Connection

(Must be purchased at the same time as a JETI 1211)

Our price: $150 USD


ADD-ON: RS‑232 Connection

(Must be purchased at the same time as a JETI 1211)

Our price: $200 USD





Sign up today to receive the latest JETI Specbos and ChromaPure news.

US orders ship USPS Priority Mail and international orders ship USPS Express Mail.
International orders may include extra import duties and/or taxes according to the laws of the target country. Contact us for custom shipping.

Payment methods include PayPal and all major credit cards
(PayPal account *not* needed to pay by credit card).
Our payment processor will automatically convert the amount
to your local currency.


Orders ship directly from our ChromaPure partner in Missouri, USA.



We've worked out an exclusive deal for our members to bring you this product at a price lower than what everyone else pays anywhere on the internet. Buy direct from our ChromaPure partner at prices lower than buying off their own website. Same product, same support, just more money in your pocket at the end of the day.

New to calibration? Give our free step by step guide a read:


Confused about meters?  See our FAQ: Which meter is right for me?



The JETI Specbos is one of the most affordable true reference color analyzers available on the market today. Just mount on a tripod, facing towards the source, connect to ChromaPure Professional and use as you would any other color analyzer.

At some point many professionals conclude that their work requires a reference colour analyzer. SMPTE has established standards for such a device. It must measure color accurately to within 0.002 xy at or above 10 cd/m2 and luminance accurately to within 0.5 cd/m2 for white field measurements. These are very exacting specifications that no tristimulus colorimeter can achieve, at least for chromaticity. For this level of accuracy you must have a 5nm spectroradiometer.

Unfortunately, such devices are not cheap. The Photo Research and Minolta reference devices start at about $15,000 USD and go up to near $30,000 USD. The X-Rite EyeOne Pro / EyeOne Pro 2 is reasonably affordable, but it is a 10nm device that cannot routinely achieve 0.002 xy accuracy. Furthermore, in addition to being expensive, true reference devices also often suffer from practical limitations. They can be slow and have problems with low-light readings.

Recently, a German company JETI Reference Instruments has developed a reference spectroradiometer, the Specbos 1211, that solve most of these problems.

First, it is relatively affordable, that is at least what passes as "affordable" in the context of reference devices. Second, it is speedy even with low luminance sources. In our testing the 1211 reads a 0.7 cd/m2 test pattern in about 13 seconds. Measurements of a 17 cd/m2 level pattern is 3 seconds or less. It is also amazingly compact and portable and includes a nifty laser spotter that allows for accurate aiming. Finally, it provides a built-in sync detector that ensures that readings will always be synchronized with the frequency of the display being measured. This feature guarantees excellent repeatability on all display types. The only feature this incredible device gives up to the established Photo Research and Minolta competitors is stand-alone operation. The Minolta and Photo Research alternatives allow for aiming through optical sights and readouts on a small LCD screen. They are fully functional devices without a PC. In contrast, the JETI device works only when attached to a PC with custom software (such as ChromaPure). For display/home theater calibration this is a non-issue as you'll be using calibration software anyway.

The 1211 can be used as a working color analyzer. Its speed and low-light sensitivity make it suitable for any calibration task—except perhaps reading black level—where the light level is so low even the 1211 often cannot cope. Fortunately, very low light levels can be accurately read with quite inexpensive instruments, such as the AEMC CA813 illuminance meter. The Display 3 will read down to about 0.007 cd/m2.


Technical Specifications

  Specbos 1211
Spectral range: 350–1000 nm
Wavelength resolution: 1 nm
Optical Bandwidth: 4.5 nm
Dynamic range (luminance): 0.2–7,000 cd/m2
Dynamic range (illuminance): 2–50,000 lux
Luminance accuracy: 2%
Luminance reproducibility: 1%
Chromaticity accuracy: 0.002 xy
Chromaticity reproducibility: 0.0005 xy
Light receiving element: 1024 pixel photodiode array
Power supply: USB
Dimensions: 180 mm x 82 mm x 53 mm
Operating temperature: 10–40 C
NIST traceable: Yes
Recommended recalibration interval: 1 Year



Calibrating Front Projectors

For best accuracy, we recommend calibrating front projectors by taking readings directly off the screen. Our JETI Specbos 1211 kits include a tripod.

What's included

  • USB cable
  • Tripod
  • Diffuser (for illuminance readings)
  • Calibration certificate
  • Operating instructions
  • Transport box with foam insert
  • ChromaPure video calibration software (optional)

Calibration DVD

For your convenience our ChromaPure partner offers a simple calibration DVD that includes all of the test patterns that you'll need to perform a complete calibration of your display. This DVD is offered free as a complementary download.

Click here to download the DVD

Instructions:

  1. Download the .zip file to your PC.
  2. Unzip the contents, which is an .iso DVD image file, to your hard drive.
  3. Double-click the .iso file.
  4. If you have DVD burning software (e.g., Nero Burning ROM), the file will open.
    Set the image type to DVD (not CD) if necessary.
  5. Insert a blank, writable DVD into your DVD burner, and then burn the image.

Reviews/Testimonials

For reviews/testimonials of ChromaPure calibration software & packages, see our ChromaPure order page.

Why buy from CurtPalme.com?

CurtPalme.com are calibration experts and authors of the popular free calibration guide: Grayscale & Color Calibration for Dummies. we live and breathe calibration. No matter what your needs we can assist in choosing what's right for you. We offer products for the budget DIY'er all the way up to the seasoned professional, all at CurtPalme.com discounted prices.

Links

ChromaPure software
ChromaPure Grayscale & Color Calibration for Dummies
Official JETI Specbos 1211 with ChromaPure forum thread
ChromaPure Discussion/Support Forum

FAQ: Which meter is right for me?
Colour Science: About Meter Accuracy
Colour Science: Video Calibration Myths
