| Author |
Message |
hotbutta
Joined: 11 Jan 2011
Posts: 8
|
| Posted: Tue Jan 11, 2011 4:42 pm Post subject: Help Sony G70 Error Code 37 FANS! |
|
|
Please help. Code 37. All fans move freely and spin on turn on. Projo shuts off immediately. After the fault, I have replaced each fan one by one with a known good fan. Each time I get the same code.
I haven't used this g70 in six years. It has beautiful, zero-wear tubes. I want to do 3d with this projector but I dont want to throw too much money at a h.o.j! Please help. I will even consider a bypass. Thanks
|
|
| Back to top |
|
 |
macgyver655
Joined: 22 Aug 2007
Posts: 8508
|
| Posted: Tue Jan 11, 2011 5:39 pm Post subject: |
|
|
|
I'm curious, how do you know the replacement fans were good? You have a spare projector?
|
|
| Back to top |
|
|
ecrabb
Forum Moderator
Joined: 13 Mar 2006
Posts: 15909
Location: Utah
TV/Projector: JVC RS40, Epson 5010
|
| Posted: Tue Jan 11, 2011 6:24 pm Post subject: |
|
|
Just as a data point, when I had a bad fan that didn't spin up, it took the projector about a second or so after startup to shut back down. When you say the projector shuts off immediately, how long is it?
I was looking the service manual, and it seems like there's a fourth fan referenced... I assume it's at the rear of the projector, but I don't recall seeing one... I only know the three behind the neckboards. Is there a fourth, Mac?
Oh, and what's an "h.o.j."?
SC
|
|
| Back to top |
|
|
macgyver655
Joined: 22 Aug 2007
Posts: 8508
|
| Posted: Tue Jan 11, 2011 6:26 pm Post subject: |
|
|
| ecrabb wrote: |
Oh, and what's an "h.o.j."?
SC |
Hunk of Junk.......... lol
|
|
| Back to top |
|
|
ecrabb
Forum Moderator
Joined: 13 Mar 2006
Posts: 15909
Location: Utah
TV/Projector: JVC RS40, Epson 5010
|
| Posted: Tue Jan 11, 2011 6:44 pm Post subject: |
|
|
| macgyver655 wrote: | | Hunk of Junk.......... lol |
Oh, hahaha... Well, in that case, I'll happily take that HOJ off his hands... For no charge!
SC
|
|
| Back to top |
|
|
hotbutta
Joined: 11 Jan 2011
Posts: 8
|
| Posted: Tue Jan 11, 2011 6:48 pm Post subject: |
|
|
I have a brand new Silenx fan that I used to test each position. And yes, it shuts off after about one second. You can see all fans spin during that time. It was just working fine. It is celing mounted near perfect. I got the screen just right. Getting ready to converge and now this!
I luv my G70. It commands respect from those that enter but I need an image to show 'em. Is there a way to bypass the shut down? Like I said, I know the fans work. Thanks
|
|
| Back to top |
|
|
macgyver655
Joined: 22 Aug 2007
Posts: 8508
|
| Posted: Tue Jan 11, 2011 7:22 pm Post subject: |
|
|
Well first thing is, does the silenx fan have a sense circuit?
Is there +15v on one of the fan wires at startup?
Edit: oh, you said they spin up on startup.
SC: where in the manual do you see a 4th fan?
|
|
| Back to top |
|
|
macgyver655
Joined: 22 Aug 2007
Posts: 8508
|
| Posted: Tue Jan 11, 2011 7:25 pm Post subject: |
|
|
|
Oh, and I wont discuss how to disable the fan circuit. To many smoked parts running without a fan.
|
|
| Back to top |
|
|
hotbutta
Joined: 11 Jan 2011
Posts: 8
|
| Posted: Tue Jan 11, 2011 7:35 pm Post subject: |
|
|
|
yeah there is a sense, its the silenx used for the g70 conversion.
|
|
| Back to top |
|
|
macgyver655
Joined: 22 Aug 2007
Posts: 8508
|
| Posted: Tue Jan 11, 2011 7:54 pm Post subject: |
|
|
Well if your +15v supply is there, and your fans spin up, AND the sense is working on all 3 fans, then you have a problem with the fan sense circuit on the MR board or YB board....or connection in between.
Edit: corrected MF to MR board.
|
|
| Back to top |
|
|
AFryia
Joined: 09 Mar 2006
Posts: 965
Location: S.E. Michigan VPH-G70Q
|
| Posted: Wed Jan 12, 2011 6:39 pm Post subject: |
|
|
| ecrabb wrote: |
I was looking the service manual, and it seems like there's a fourth fan referenced... I assume it's at the rear of the projector, but I don't recall seeing one... |
That because it's not there
There may be a provision on the PCB for a fouth.
|
|
| Back to top |
|
|
ecrabb
Forum Moderator
Joined: 13 Mar 2006
Posts: 15909
Location: Utah
TV/Projector: JVC RS40, Epson 5010
|
| Posted: Wed Jan 12, 2011 7:58 pm Post subject: |
|
|
| AFryia wrote: | | ecrabb wrote: |
I was looking the service manual, and it seems like there's a fourth fan referenced... I assume it's at the rear of the projector, but I don't recall seeing one... |
That because it's not there |
I figured... I just thought it was weird what I saw... I just glanced at the service manual for about 30 seconds and I didn't even zoom in, so obviously I misread it.
SC
|
|
| Back to top |
|
|
hotbutta
Joined: 11 Jan 2011
Posts: 8
|
| Posted: Thu Jan 13, 2011 3:33 pm Post subject: |
|
|
|
0's and 1's here I come.
|
|
| Back to top |
|
|
hotbutta
Joined: 11 Jan 2011
Posts: 8
|
| Posted: Sat Feb 19, 2011 12:28 am Post subject: |
|
|
Well I am on the flip-side. At least its still Sony!
| Description: |
|
| Filesize: |
140.84 KB |
| Viewed: |
4571 Time(s) |
|
|
|
| Back to top |
|
|
|
|
